Green Cell UPS 850VA 480W PowerProof with LCD Screen User Manual

1. Įvadas ir pabaigaview

An Uninterruptible Power Supply (UPS) is a device designed to provide temporary electrical power during a power outage. This ensures the continuous operation of critical equipment, preventing data loss, hardware damage, and security system interruptions. The Green Cell UPS 850VA 480W PowerProof is engineered to protect your sensitive devices, such as computers, routers, and network equipment, from power failures, voltage surges, and fluctuations.

This manual provides essential information for the safe and efficient use of your Green Cell UPS. Please read it thoroughly before installation and operation.

2. Saugos instrukcijos

To ensure safe operation and prevent damage to the unit or connected devices, observe the following safety precautions:

• Neatidarykite UPS korpuso.asing. Viduje nėra dalių, kurias galėtų aptarnauti vartotojas. Visus techninės priežiūros darbus patikėkite kvalifikuotiems techninės priežiūros darbuotojams.
• Keep the UPS away from water, excessive humidity, and extreme temperatures.
• Ensure adequate ventilation around the UPS. Do not block ventilation openings.
• Connect the UPS only to a grounded electrical outlet.
• Do not connect non-computer related equipment (e.g., medical equipment, life support systems) to the UPS.
• Disconnect the UPS from the power outlet before cleaning. Use a dry cloth only.
• The battery inside the UPS is not user-replaceable. Battery replacement should only be performed by qualified personnel.

3. Pakuotės turinys

Patikrinkite, ar pakuotėje yra visi reikalingi daiktai:

• Green Cell UPS 850VA 480W PowerProof Unit
• Vartotojo vadovas (šis dokumentas)
• Maitinimo kabelis

4. Produkto ypatybės

The Green Cell UPS 850VA 480W PowerProof offers a range of features designed for optimal power protection and user convenience:

• Reliable Power Protection: Safeguards sensitive devices against power outages, viršįtampius ir ttage svyravimai.
• LCD ekranas: An integrated LCD provides clear information on the UPS's current operating status, including battery status, input/output voltage, and error messages.
• Nepertraukiamas maitinimo šaltinis: Features a fast switching time of 2-6ms, ensuring continuous power to your devices during sudden power cuts.
• Long Backup Power: Equipped with a durable 12V/9Ah battery, providing reliable backup power until mains electricity is restored.
• Apsauga nuo viršįtampių: Offers comprehensive protection against surges and short circuits caused by sudden power spikes.
• AVR System: Automatinis ttage Regulation (AVR) system controls voltage to protect your hardware.
• Šalto paleidimo režimas: Allows the UPS to be started without being connected to the mains power supply.
• RJ45 prievadai: Additional RJ45 ports for network protection.

Figure 4.1: Easy connection and immediate device protection with RJ45 ports, surge protection, and fast switching time.

Figure 4.2: Cold Start Mode allows using the UPS without mains connection, as shown in a photography studio setting.

4.3 pav.: ttage control through the AVR system ensures the safety of your equipment, depicted in a home environment.

5. Sąrankos instrukcijos

Follow these steps to set up your Green Cell UPS:

1. Išpakuokite UPS: Atsargiai išimkite UPS iš pakuotės. Patikrinkite, ar nėra jokių transportavimo pažeidimų.
2. Vieta: Place the UPS in a cool, dry, and well-ventilated area. Avoid direct sunlight, heat sources, and areas with excessive dust or moisture. Ensure there is sufficient space around the unit for airflow.
3. Pradinis įkrovimas: Before connecting any devices, plug the UPS into a standard grounded wall outlet using the provided power cable. Allow the UPS to charge for at least 5 hours to ensure the battery is fully charged. This is crucial for optimal battery performance.
4. Prijunkite įrenginius: Once the UPS is fully charged, connect your computer, monitor, router, and other sensitive electronic devices to the output sockets on the back of the UPS. Do not overload the UPS beyond its rated capacity (480W).
5. Maitinimas: Press the power button on the front panel of the UPS to turn it on. The LCD screen will illuminate, indicating the UPS is operational.

6. Naudojimo instrukcijos

Understanding the operation of your UPS is key to maximizing its benefits.

6.1 Įjungimas / išjungimas

• Įjungti: Press and hold the power button for approximately 2 seconds until you hear a beep and the LCD screen illuminates.
• Išjungti: Press and hold the power button for approximately 2 seconds until the LCD screen turns off.

6.2 LCD ekranas

The LCD screen provides real-time information about the UPS status:

Figure 6.1: The LCD screen displays essential operating parameters for user convenience.

• Įvesties tomastage (VAC INPUT): Rodo esamą tūrįtage from the mains power supply.
• Išėjimas ttage (VAC OUTPUT): Rodo ttage, kurią tiekia UPS prijungtiems įrenginiams.
• Battery Status (Batt. Mode): Indicates the current charge level of the internal battery.
• Apkrovos lygis: Rodo proctage UPS pajėgumų, kuriuos šiuo metu naudoja prijungti įrenginiai.
• Veikimo režimas: Displays the current operating mode (e.g., Line Mode, Battery Mode).

6.3 Šaltojo užvedimo funkcija

The cold start function allows you to power on the UPS and connected devices using only battery power, even if there is no mains power available. To activate, ensure the UPS is off, then press and hold the power button until the UPS starts and provides power to the outlets.

7. Priežiūra

Tinkama priežiūra užtikrina jūsų UPS ilgaamžiškumą ir optimalų veikimą.

• Akumuliatoriaus priežiūra: To prolong battery life, ensure the UPS is connected to mains power and fully charged at all times. If the UPS is stored for an extended period, recharge it every 3 months to prevent battery discharge.
• Valymas: Prieš valydami atjunkite UPS nuo maitinimo lizdo. Išorę nuvalykite minkšta, sausa šluoste. Nenaudokite skystų ar aerozolinių valiklių.
• Vėdinimas: Regularly check that the ventilation openings are clear of dust and obstructions to prevent overheating.
• Baterijos keitimas: The internal battery is a sealed lead-acid type and is not user-replaceable. If the battery needs replacement, contact qualified service personnel or Green Cell support.

8. Problemų sprendimas

Jei kyla problemų dėl UPS, žr. šias dažniausiai pasitaikančias problemas ir sprendimus:

If the problem persists after attempting these solutions, please contact Green Cell customer support.

9. Specifikacijos

Detailed technical specifications for the Green Cell UPS 850VA 480W PowerProof:

10. Garantija ir palaikymas

10.1 Informacija apie garantiją

This Green Cell UPS is covered by a 2 metų gamintojo garantija from the date of purchase. This warranty covers defects in materials and workmanship under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or improper installation.

10.2 Pagalba klientams

For technical assistance, warranty claims, or any questions regarding your Green Cell UPS, please contact our customer support team. Please have your model number (UPSLM480) and proof of purchase ready when contacting support.

Kontaktinė informacija:
Websvetainė: www.greencell.global
Email: [Please refer to the Green Cell website for the most current contact email]
Phone: [Please refer to the Green Cell website for the most current contact phone number]
