1. Produktas baigtasview
This manual provides instructions for the installation, operation, and maintenance of the WELLS Electric Thermostat Dial, Model 130-1003 (Part Reference 67172). This dial is designed for controlling electric heating elements within a temperature range of 100°F to 200°F. It features a universal 4-way mounting position and is compatible with standard .187" diameter D-stems.
1 paveikslas: WELLS Electric Thermostat Dial, Model 130-1003. This image shows the black plastic dial with a chrome-plated face, designed for temperature control.
2. Saugos informacija
Read all instructions carefully before installing or operating this device. Failure to follow these instructions may result in electric shock, fire, or property damage.
- Elektros pavojus: Ensure power is disconnected before installation or maintenance. Only qualified personnel should perform electrical work.
- Temperature Hazard: The thermostat controls heating elements. Surfaces may become hot. Exercise caution to prevent burns.
- Tinkamas naudojimas: Use this thermostat only for its intended purpose as an electric temperature control dial. Do not modify the device.
- Aplinkos sąlygos: Nelaikykite įrenginio per didelėje drėgmėje ar ekstremalioje temperatūroje, viršijančioje jo veikimo diapazoną.
3. Sąranka ir diegimas
This section outlines the general steps for installing the thermostat dial. Consult your equipment's specific wiring diagram and installation instructions for detailed guidance.
3.1 Patikrinimai prieš montavimą
- Verify that the power supply to the equipment is completely disconnected.
- Confirm that the existing thermostat's D-stem diameter matches the .187" requirement of this dial.
- Ensure the mounting area is clean and free from debris.
3.2 Mounting the Dial
- Carefully align the D-shaped opening on the back of the thermostat dial with the D-stem of the control unit.
- Gently push the dial onto the stem until it is fully seated. The universal 4-way mounting allows for flexible orientation.
- Ensure the dial rotates smoothly without obstruction and that the temperature markings align correctly with the indicator on the control panel.
4. Naudojimo instrukcijos
The WELLS Electric Thermostat Dial provides simple and intuitive temperature control.
4.1 Temperatūros nustatymas
- After installation and power restoration, turn the dial clockwise or counter-clockwise to select the desired temperature.
- The temperature range for this dial is from 100°F to 200°F.
- The heating element will activate or deactivate to maintain the set temperature.
4.2 Understanding the Dial Markings
The chrome-plated face of the dial features clear markings indicating temperature settings. Align the indicator on your equipment's control panel with the desired temperature on the dial.
5. Priežiūra
Regular maintenance ensures optimal performance and longevity of your thermostat dial.
5.1 Valymas
- Prieš valydami, įsitikinkite, kad įranga yra išjungta ir atvėsusi.
- Wipe the dial's surface with a soft, damp audinys.
- Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the plastic and chrome finish.
5.2 Patikra
- Periodically inspect the dial for any signs of wear, cracks, or damage.
- Ensure the dial remains securely attached to the D-stem.
- If any damage is observed, replace the dial immediately to prevent operational issues.
6. Problemų sprendimas
This section addresses common issues you might encounter with the thermostat dial.
| Problema | Galima priežastis | Sprendimas |
|---|---|---|
| Dial does not turn or is stiff. | Incorrect alignment with D-stem; debris; damaged stem. | Remove dial and re-align. Clean any debris. Inspect D-stem for damage. |
| Temperature setting does not respond. | Dial not fully seated on D-stem; internal control unit issue. | Ensure dial is fully seated. If issue persists, consult equipment's service manual or a qualified technician. |
| Dial appears loose. | Improper installation; worn D-stem or dial opening. | Re-seat the dial firmly. If it remains loose, consider replacing the dial or inspecting the D-stem for wear. |
For issues not listed here, or if troubleshooting steps do not resolve the problem, contact a qualified service technician or the manufacturer.
7. Gaminio specifikacijos
| Prekės ženklas | Wells |
| Modelio numeris | 130-1003 |
| Dalies nuoroda | 67172 |
| Medžiaga | Plastikiniai |
| Valdymo tipas | Rinkimo valdymas |
| Temperatūros diapazonas | 100°F iki 200°F |
| D-Stem Compatibility | Standard .187" diameter |
| Montavimas | Universal 4-way positions |
| Spalva | Black with Chrome-Plated Face |
| Gaminio matmenys | 2 x 2 x 2 colio |
| Prekės svoris | 0.48 uncijos (apie 13.61 g) |
| UPC | 251301003911 |
8. Informacija apie garantiją
Specific warranty details for the WELLS Electric Thermostat Dial, Model 130-1003, are not provided in this manual. For information regarding warranty coverage, terms, and conditions, please refer to the documentation included with your purchase or contact the original seller or the manufacturer directly.
9. Pagalba klientams
If you require technical assistance, have questions about the product, or need to report an issue, please contact the retailer from whom you purchased the WELLS Electric Thermostat Dial or visit the official Wells Manufacturing webpalaikymo išteklių svetainė.
