Ozeri Rev Digital Kitchen Scale ZK18-WG Instruction Manual

1. Produktas baigtasview

The Ozeri Rev Digital Kitchen Scale combines a digital display with an electro-mechanical dial to provide precise weight measurements. It is designed for accuracy and ease of use in various kitchen tasks.

1.1 paveikslas: Į viršų view of the Ozeri Rev Digital Kitchen Scale, showing the digital display and the mechanical dial.

The scale features high-precision sensors capable of weighing items from 0.1 oz to 11 lbs (5000 g) with graduations of 0.1 oz or 1 gram. It offers a dual display system for both digital and mechanical readings.

2. Sąranka

2.1 Išpakavimas

Carefully remove the scale from its packaging. Inspect the scale for any signs of damage. Retain the packaging for future storage or transport.

2.2 Akumuliatoriaus įdėjimas

The Ozeri Rev Digital Kitchen Scale requires 3 AAA batteries (included). Follow these steps to install them:

1. Apatinėje svarstyklių pusėje raskite baterijos skyrių.
2. Open the battery compartment cover. No screwdriver is needed for this.
3. Įdėkite 3 AAA tipo baterijas, užtikrindami teisingą poliškumą (+/-), kaip nurodyta skyrelio viduje.
4. Saugiai uždarykite akumuliatoriaus skyriaus dangtelį.

Pastaba: If the included batteries appear leaked or damaged, do not use them. Replace with new AAA batteries.

2.3 Pradinis išdėstymas

Place the scale on a flat, stable, and hard surface to ensure accurate readings. Avoid placing it on soft or uneven surfaces, which can affect precision.

3. Naudojimo instrukcijos

3.1 Maitinimo įjungimas/išjungimas

• Norėdami pasukti svarstykles ON, paspauskite ĮJUNGTA/IŠJUNGTA button located on the front panel. The LCD and mechanical dial will illuminate.
• Norėdami pasukti svarstykles IŠJUNGTA, paspauskite ir palaikykite ĮJUNGTA/IŠJUNGTA button for a few seconds. The scale also features an automatic shut-off function to conserve battery power if left inactive.

3.1 paveikslas: Iš arti view of the digital display, mechanical dial, TARE button, and ON/OFF button.

3.2 Vieneto konvertavimas

The scale can display measurements in various units. To change the unit of measurement:

• Locate the unit conversion button. This is typically a VIENETAS button or a physical switch on the underside of the scale.
• Paspauskite VIENETAS button or toggle the switch to cycle through available units: pounds (lb), ounces (oz), grams (g), and milliliters (ml).
• The selected unit will be displayed on the LCD screen. The mechanical dial simultaneously shows measurements in lbs and kg for heavier items.

3.3 Taros funkcija

The Tare function allows you to weigh ingredients in a container by subtracting the container's weight. This enables you to measure multiple ingredients consecutively in the same bowl.

1. Padėkite tuščią indą ant svarstyklių.
2. Paspauskite TARĖ mygtuką. Ekranas bus atstatytas į nulį.
3. Add your ingredient to the container. The scale will display only the weight of the ingredient.
4. Pakartokite procesą su papildomais ingredientais.

Pastaba: Some users report a slight delay (approx. 3 seconds) for the Tare function to register. If the Tare function does not work immediately after turning the scale on, try placing the container on the scale prieš powering it on, then press Tare.

3.4 Svėrimo elementai

Norėdami pasverti prekę:

1. Įsitikinkite, kad svarstyklės pastatytos ant lygaus, stabilaus paviršiaus ir įjungtos.
2. Jei naudojate konteinerį, atlikite taros funkciją, kaip aprašyta aukščiau.
3. Place the item(s) to be weighed gently onto the center of the scale platform.
4. Read the weight displayed on the digital LCD screen and observe the mechanical dial for a visual representation of heavier weights.

3.2 paveikslas: The scale accurately weighing strawberries in a bowl.

3.3 paveikslas: The scale displaying the weight of chocolate chips in a measuring cup.

4. Priežiūra

4.1 Valymas

The Ozeri Rev Digital Kitchen Scale features a glass top, making it easy to clean.

• Svarstyklių paviršių nuvalykite minkšta,amp audinys.
• For stubborn stains, use a mild detergent solution on the cloth, then wipe clean with a damp skudurėliu ir gerai išdžiovinkite.
• Do not immerse the scale in water or use abrasive cleaners, as this can damage the electronic components.

4.2 Saugykla

Store the scale in a cool, dry place away from extreme temperatures and humidity. Its compact size allows for easy storage in most kitchen drawers or cabinets.

4.3 Akumuliatoriaus keitimas

When the low battery indicator appears on the LCD, replace all three AAA batteries with new ones to ensure continued accurate operation. Refer to Section 2.2 for battery installation instructions.

5. Problemų sprendimas

5.1 Netikslūs rodmenys

• Nelygus paviršius: Ensure the scale is placed on a flat, stable, and hard surface.
• Perkrova: Do not exceed the maximum weight capacity of 11 lbs (5000 g). Overloading can damage the sensors.
• Senka baterija: Replace batteries if the low battery indicator is on, as low power can affect accuracy.
• Kalibravimas: While the scale is factory calibrated, consistent inaccuracies may require contacting customer support.

5.2 Tare Function Issues

• Vėlavimas: The Tare function may have a slight delay. Press the TARE button and wait a few seconds for the display to zero out.
• Initial Tare: If the Tare function is unresponsive after power-on, try placing the container on the scale prieš turning the scale on, then press TARE.

5.3 Ekranas neveikia

• Nėra galios: Check if the scale is turned on.
• Išsikrovusios baterijos: Pakeiskite AAA tipo baterijas.
• Baterijos padėtis: Įsitikinkite, kad baterijos įdėtos teisingu poliškumu.

6. Specifikacijos

7. Garantija ir palaikymas

For warranty information or technical support, please refer to the documentation included with your purchase or visit the official Ozeri website. The product has an EU Spare Part Availability Duration of 2 Years.

For further assistance, you may contact Ozeri customer service through their official channels.
