Anpviz 4MP PoE Dome Security Camera User Manual

1. Produktas baigtasview

The Anpviz 4MP PoE Dome Security Camera (IPC-D240W-S) is a versatile surveillance solution designed for both indoor and outdoor use. It features a 4-megapixel high-definition resolution, Power over Ethernet (PoE) for simplified installation, and a 2.8mm wide-angle lens providing a 108° field of view. Equipped with IR night vision up to 30 meters and a built-in microphone for one-way audio, this camera offers comprehensive monitoring capabilities. Its IP66 weatherproof metal housing ensures durability in various environmental conditions.

Vaizdas: Viršview of the Anpviz 4MP PoE Dome Security Camera, highlighting its dimensions and key features such as 4MP resolution, motion detection, IR night vision, built-in mic, 2.8mm lens, 1/3" CMOS sensor, H.265 compression, IP66 waterproof rating, and IK10 vandal proofing.

2. Kas yra dėžutėje

Atidarę pakuotę, patikrinkite, ar yra visi šie komponentai:

• Anpviz 4MP PoE Dome IP Camera (IPC-D240W-S)
• Vandeniui atsparus dangtelis
• Montavimo varžtai
• Quick Operation Guide / Manual
• Warning Sticker (Video Surveillance)
• Mounting Kit (includes Allen key)
• Network Port Waterproof Kit
• Paslaugos kortelė

Image: A visual representation of all items included in the Anpviz 4MP PoE Dome Security Camera package, laid out on a white surface.

3. Sąranka ir diegimas

3.1 Prisijungimo būdai

The Anpviz 4MP PoE Dome Security Camera offers flexible connection options:

1. Connect via Anpviz NVR PoE: Connect the camera directly to an Anpviz Network Video Recorder (NVR) with PoE ports using an Ethernet cable. The NVR will provide both power and data.
2. Connect by DC12V Power Supply: Use a standard DC12V power adapter (not included) to power the camera, and connect it to your router via an Ethernet cable for data.
3. Connect via PoE Injector or PoE Switch: Use a PoE injector or a PoE switch to provide power and data to the camera through a single Ethernet cable, then connect the injector/switch to your router.

Video: This video demonstrates three different methods to connect your Anpviz Uprime Series PoE IP Camera: directly to an NVR, using a DC12V power supply, or via a PoE injector/switch.

Image: A detailed diagram illustrating how to connect the Anpviz PoE camera to an NVR system, including connections for monitor, mouse, router, and power.

3.2 Software Installation and Initial Configuration

Tvarkyti ir view your camera, you will need to install the appropriate software:

1. Atsisiųskite programinę įrangą: Visit the Anpviz Security websvetainė (www.anpvizsecurity.com) and navigate to the 'Download' section. Download the 'SearchTool' and 'LMS Client' software for your operating system (Windows/Mac).
2. Find Camera IP Address: Use the 'SearchTool' to discover your camera's IP address on your local network.
3. Prieiga prie fotoaparato Web Sąsaja: Atidarykite a web browser (e.g., Firefox, Google Chrome, Edge) and enter the camera's IP address to log in. The default username and password can be found in your user manual.
4. P2P Setup for Mobile App: In the camera's web interface, navigate to the 'Configuration' > 'Network' > 'P2P' section. Enable P2P and locate the QR code.
5. Add Camera to Mobile App: Download the 'Danale' mobile app (available on Google Play and App Store). In the app, select to add a new device and scan the QR code displayed on the camera's web interface. Follow the on-screen prompts to name your device and complete the setup.

Video: This video provides a step-by-step guide on how to add your Anpviz camera to the Danale mobile application for live preview ir nuotolinė prieiga.

4. Operacija

4.1 Tiesiogiai View

Once your camera is set up and connected, you can access the live video feed through the Danale mobile app or the LMS Client software on your PC. This allows for real-time monitoring of your premises.

Paveikslėlis: Vartotojas viewing live camera footage on a smartphone, demonstrating remote access capabilities via the VideoLink mobile app and LMS/VideoLink PC client.

4.2 Judesio aptikimas

The camera features real-time motion detection. When movement is detected within the camera's field of view, an alert is triggered. You can configure the system to send alarm notifications directly to your smartphone via the VideoLink app or to your PC.

Image: An illustration of the camera's smart human detection feature, showing a person highlighted in the camera's view and corresponding alert notifications on a smartphone.

4.3 IR naktinio matymo funkcija

The camera is equipped with infrared (IR) night vision, providing clear surveillance even in low-light or complete darkness. The IR night vision range extends up to 30 meters, ensuring continuous monitoring around the clock.

Image: A split image comparing the camera's view during daytime (color) and nighttime (black and white with IR illumination), demonstrating its night vision capabilities.

4.4 Garso įrašymas

A built-in microphone allows for one-way audio recording, capturing sound from the camera's vicinity. This feature can provide additional context to video footage.

Image: An illustration showing the camera's built-in microphone capturing audio, with a delivery person speaking and the sound being heard through a smartphone app.

5. Priežiūra

5.1 Atsparumas oro sąlygoms

The Anpviz 4MP PoE Dome Security Camera features an IP66 weatherproof metal housing, making it suitable for outdoor use. It is designed to withstand extreme temperatures, dust, and rain, ensuring reliable operation in various weather conditions.

Video: This video demonstrates the IP66 waterproof rating of the Anpviz camera, showing it functioning effectively under rain and snow, and its resistance to extreme temperatures.

Image: The Anpviz camera shown with icons representing sunny, rainy, and snowy conditions, along with a temperature range, indicating its IP66 weatherproof capabilities.

5.2 Valymas

To ensure optimal performance and image clarity, periodically clean the camera lens and housing. Use a soft, damp šluoste nuvalykite dulkes ir nešvarumus. Venkite naudoti stiprias chemines medžiagas ar abrazyvines medžiagas, kurios gali pažeisti objektyvą ar apdailą.

6. Problemų sprendimas

• Nėra vaizdo / vaizdo įrašo: Check all cable connections (Ethernet, power). Ensure the camera is receiving power and the network connection is active. Verify the camera's IP address and network settings using the SearchTool.
• Prasta vaizdo kokybė: Ensure the lens is clean and free from obstructions. Check network bandwidth if streaming is choppy. Adjust camera settings for resolution and compression if necessary.
• Judesio aptikimas neveikia: Verify that motion detection is enabled in the camera's configuration. Adjust sensitivity settings and detection zones to suit your environment.
• Nepavyksta nuotoliniu būdu pasiekti kameros: Ensure P2P is enabled and showing an 'Online' status in the camera's web interface. Check your router's internet connection. Verify that the Danale app is correctly configured and the camera is added.
• Camera Not Found by SearchTool: Ensure the camera and the computer running SearchTool are on the same local network segment. Temporarily disable any firewall software on your computer that might block network discovery.

7. Specifikacijos

8. Garantija ir palaikymas

Anpviz products come with a standard manufacturer's warranty. For detailed warranty information, technical support, or service inquiries, please refer to the official Anpviz Security websvetainėje arba susisiekite tiesiogiai su jų klientų aptarnavimo tarnyba. Išsaugokite pirkimo kvitą garantiniams reikalavimams.

Internetiniai ištekliai:

• Oficialus Websvetainė: www.anpvizsecurity.com
• Support Center: Check the website for FAQs, troubleshooting guides, and firmware updates.
