STATIK 100W GaN Charger Instruction Manual

Įvadas

The STATIK 100W GaN Charger is a high-performance, multi-port wall charger designed for efficient and fast charging of various electronic devices. Utilizing advanced GaN (Gallium Nitride) technology, this charger offers a compact design, reduced heat generation, and improved power efficiency. It features multiple USB-C and USB-A ports to charge up to four devices simultaneously.

• Itin greitas įkrovimas: Užtikrina iki 100 W galią greitam įkrovimui.
• Pažangi GaN technologija: Ensures a compact size, lower heat, and higher charging efficiency.
• Visuotinis suderinamumas: Supports a wide range of devices including MacBook Pro/Air, iPad, iPhone, Samsung Galaxy, Nintendo Switch, and more.
• Overheat and Overload Protection: Built-in safety features protect against overheating, overloading, and short circuits.
• Kompaktiškas ir nešiojamas: Designed for easy travel and everyday use with a foldable plug.

Image: The STATIK 100W GaN Charger in use, demonstrating its high-speed charging for a laptop.

Image: The compact design of the STATIK 100W GaN Charger compared to a larger standard charger.

Pakuotės turinys

Prašome patikrinti, ar pakuotėje yra visi reikalingi daiktai:

• STATIK 100W GaN Charger (Model: PUP-0295)
• Instrukcijų vadovas (šis dokumentas)

Sąranka

Follow these steps to set up your STATIK 100W GaN Charger:

1. Išskleiskite kištuką: Gently unfold the AC prongs from the charger body. The charger features a foldable plug for portability.


Image: The STATIK 100W GaN Charger showing its four ports (3 USB-C, 1 USB-A) and the foldable AC plug in both folded and unfolded positions.

2. Prijunkite prie maitinimo lizdo: Insert the charger's prongs into a standard wall power outlet. Ensure it is securely plugged in.


Image: The charger plugged into a wall socket, demonstrating its use with multiple devices.

3. Prijunkite įrenginius: Use appropriate charging cables (not included) to connect your devices to the available USB-C or USB-A ports on the charger.

Naudojimo instrukcijos

The STATIK 100W GaN Charger is designed for simple plug-and-play operation. It automatically detects connected devices and delivers optimal charging power.

Charging Single Device:

Connect your device to any available USB-C or USB-A port using a compatible cable. For maximum speed, especially for laptops or high-power devices, use one of the USB-C ports (USB-C1 or USB-C2) which can deliver up to 100W individually.

Kelių įrenginių įkrovimas:

The charger can power up to four devices simultaneously. The total 100W power output is dynamically distributed among the connected ports. Refer to the power distribution guide below for typical scenarios.

Image: The charger's universal compatibility with a range of devices including iPhones, iPads, laptops, and gaming consoles.

Image: The charger actively charging four devices at once, including a laptop, tablet, smartphone, and wireless earbuds.

Power Output Configuration:

The charger intelligently adjusts power output based on the number and type of connected devices. Below are common power distribution scenarios:

• Vienas įrenginys: USB-C1 or USB-C2: Up to 100W; USB-C3: Up to 65W; USB-A: Up to 30W.
• Two Devices:
  • USB-C1 (65 W) + USB-C2 (30 W)
  • USB-C1 (65 W) + USB-C3 (30 W)
  • USB-C1 (65 W) + USB-A (30 W)
  • USB-C2 (65 W) + USB-C3 (30 W)
  • USB-C2 (65 W) + USB-A (30 W)
  • USB-C3 (30 W) + USB-A (30 W)
• Three Devices:
  • USB-C1 (45W) + USB-C2 (30W) + USB-C3 (7.5W)
  • USB-C1 (45 W) + USB-C2 (30 W) + USB-A (7.5 W)
• Four Devices: USB-C1 (45W) + USB-C2 (35W) + USB-C3 (7.5W) + USB-A (7.5W)

Image: Visual representation of the charging guide, illustrating maximum power output for single and multiple device connections across USB-C and USB-A ports.

Priežiūra

To ensure the longevity and optimal performance of your charger, follow these maintenance guidelines:

• Valymas: Prieš valydami atjunkite įkroviklį nuo maitinimo lizdo ir visų įrenginių. Paviršiui nuvalyti naudokite minkštą, sausą šluostę. Nenaudokite skystų valiklių ar aerozolių.
• Saugykla: When not in use, store the charger in a cool, dry place away from direct sunlight and extreme temperatures. Fold the prongs for compact storage.
• Venkite drėgmės: Do not expose the charger to water or excessive humidity.
• Elkitės atsargiai: Venkite įkroviklio numetimo ir stiprių smūgių.

Trikčių šalinimas

If you encounter issues with your STATIK 100W GaN Charger, refer to the following common problems and solutions:

Specifikacijos

Saugos informacija

Your safety and the safety of your devices are paramount. The STATIK 100W GaN Charger incorporates multiple safety features:

• Apsauga nuo perkaitimo: Prevents the charger from exceeding safe operating temperatures.
• Apsauga nuo perkrovos: Apsauga nuo per didelio srovės suvartojimo.
• Trumpojo jungimo apsauga: Apsaugo nuo pažeidimų, kuriuos sukelia trumpieji jungimai.

Always use the charger in a well-ventilated area and avoid covering it during operation. Do not attempt to disassemble or modify the charger.

Garantija ir palaikymas

For product support, technical assistance, or warranty inquiries, please contact Statik customer service. Refer to the official Statik webkontaktinę informaciją rasite svetainėje arba pirkimo dokumentuose.

This product is manufactured by Curv Group LLC.
