Sygonix SY-5773110 Instant Water Heater 3000W User Manual

1. Įvadas

Thank you for choosing the Sygonix SY-5773110 Instant Water Heater. This device provides flexible and efficient hot water directly from your faucet, eliminating the need for a separate hot water tank. It heats water on demand, saving energy by only activating when hot water is required. This manual provides essential information for the safe installation, operation, and maintenance of your instant water heater. Please read it thoroughly before use and keep it for future reference.

Figure 1: Sygonix SY-5773110 Instant Water Heater faucet unit.

2. Saugos informacija

Kad išvengtumėte sužalojimų ir įrenginio pažeidimų, laikykitės šių saugos priemonių:

• Elektros sauga: Ensure the device is connected to a properly grounded power outlet. Water and electricity are double insulated within the unit for enhanced safety.
• Šiluminė apsauga: The unit is equipped with a thermal fuse for additional protection against overheating.
• Vandens slėgis: Ensure the water pressure is within the recommended range for optimal operation and to prevent damage.
• Montavimas: Installation must be performed by a qualified professional or a person with adequate knowledge of plumbing and electrical systems.
• IP24 sertifikatas: The device is IP24 certified, meaning it is protected against splashing water from any direction. However, it should not be submerged in water.
• Vaikai ir pažeidžiami asmenys: Šį prietaisą gali naudoti vaikai nuo 8 metų ir asmenys, turintys ribotų fizinių, jutiminių ar protinių gebėjimų arba neturintys patirties ir žinių, jei jie yra prižiūrimi arba yra instruktuojami, kaip saugiai naudoti prietaisą ir supranta su tuo susijusius pavojus. .
• Priežiūra: Prieš atlikdami bet kokius priežiūros ar valymo darbus, atjunkite maitinimą.

3. Pakuotės turinys

Atsargiai išpakuokite dėžę ir įsitikinkite, kad visos dalys yra nepažeistos. Jei trūksta kokių nors dalių arba jos pažeistos, nedelsdami susisiekite su pardavėju.

• Sygonix SY-5773110 Instant Water Heater Faucet Unit
• Maitinimo kabelis su kištuku
• Mounting Hardware (washers, nuts, seals)
• Vartotojo vadovas (šis dokumentas)

2 pav. Baigtaview of the instant water heater and its components.

4. Sąranka ir diegimas

The Sygonix SY-5773110 is designed for easy installation, integrating directly into your existing faucet setup. All necessary installation parts are included.

1. Paruoškite montavimo vietą: Ensure the water supply is turned off at the main valve before beginning installation. Clear the area under the sink for easy access.
2. Sumontuokite maišytuvą: Insert the threaded pipe of the instant water heater faucet into the mounting hole on your sink or countertop.
3. Pritvirtinkite čiaupą: From underneath the sink, place the rubber washer, metal washer, and then the locking nut onto the threaded pipe. Tighten the locking nut securely to prevent movement.
4. Prijunkite vandens tiekimą: Connect the cold water supply line to the designated inlet on the faucet unit. Ensure all connections are tight to prevent leaks. Note: This unit is designed for cold water input only, as it heats the water internally.
5. Prijunkite maitinimą: Plug the power cable into a standard, grounded 230V AC electrical outlet. Ensure the outlet is easily accessible and not exposed to water.
6. Patikrinkite, ar nėra nuotėkių: Slowly turn on the main water supply and check all connections for any leaks. Tighten connections if necessary.
7. Pradinis praplovimas: Before first use, allow cold water to run through the faucet for a few minutes to flush out any air from the system.

Figure 3: Installation diagram illustrating the faucet unit and power connection under the sink.

5. Naudojimo instrukcijos

The Sygonix SY-5773110 is designed for straightforward operation, providing hot water within 3 to 5 seconds.

1. Įjunkite vandenį: Lift the control lever to turn on the water flow.
2. Reguliuoti temperatūrą: Rotate the control lever to select the desired water temperature. The digital LED temperature display will show the current temperature.
   • Move the lever towards the mėlyna indicator for colder water.
   • Move the lever towards the raudona indicator for warmer water.
3. Momentinis šildymas: The integrated stainless steel heating coil will rapidly heat the water as it flows through the faucet to your selected temperature.
4. Water-Saving Spout: The special water outlet design helps reduce water consumption, contributing to lower utility costs.
5. Išjunkite vandenį: Push the control lever down to stop the water flow.

6. Priežiūra

Regular maintenance ensures the longevity and efficient operation of your instant water heater.

• Valymas: Clean the exterior of the faucet with a soft, damp šluoste. Nenaudokite abrazyvinių valiklių ar tirpiklių, nes jie gali pažeisti apdailą.
• Nukalkinimas: In areas with hard water, mineral deposits (limescale) can build up over time. If water flow decreases or heating efficiency drops, descaling may be necessary. Consult a qualified plumber for descaling procedures or use a suitable descaling agent designed for water heaters, following its instructions carefully.
• Filtro valymas: Periodically check and clean any inlet filters to ensure unobstructed water flow.
• Žieminimas (jei taikoma): If the device is installed in an area where temperatures can drop below freezing, ensure the unit is drained to prevent damage from freezing water.
• Profesionalus patikrinimas: It is recommended to have the unit inspected by a qualified professional every few years.

7. Problemų sprendimas

If you encounter issues with your instant water heater, refer to the following table for common problems and solutions.

If the problem persists after attempting these solutions, please contact customer support. Do not attempt to repair the unit yourself.

8. Techninės specifikacijos

Figure 4: Energy efficiency label for the Sygonix SY-5773110.

9. Informacija apie garantiją

The Sygonix SY-5773110 Instant Water Heater comes with a minimum 2 metų garantija from the date of purchase. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims. The warranty does not cover damage resulting from improper installation, misuse, neglect, accidents, or unauthorized repairs.

10. Pagalba klientams

If you have any questions, require technical assistance, or need to make a warranty claim, please contact your retailer or the Sygonix customer support team. Please have your model number (SY-5773110) and proof of purchase ready when contacting support.
