VEVOR 480ml Bluetooth Smart Essential Oil Diffuser (Model A501) Instruction Manual

1. Svarbios saugos instrukcijos

• Venkite tiesioginio sąlyčio su oda su neskiestais eteriniais aliejais.
• Laikyti vaikams ir naminiams gyvūnėliams nepasiekiamoje vietoje.
• Naudojimo metu užtikrinkite tinkamą vėdinimą.
• Nenurykite eterinių aliejų.
• Use only recommended essential oils for diffusers.

2. Pakuotės turinys

Patikrinkite, ar pakuotėje yra visi šie daiktai:

• 1 x VEVOR Scent Air Machine (Model A501)
• 1 x Vartotojo vadovas
• 1x maitinimo adapteris
• 2 x Hardware Keys
• 1 x Self-sealing Bag
• 2 x Galvanized Cement Nails (M6x25)
• 2 x Green Adhesive Pellets
• 1 x Plastic Bottle Cap
• 2 x Countersunk Galvanized Gross Self-Tapping Screws (M4x20)
• 1 x Atomization Core Assembly

3. Produktas baigtasview

The VEVOR 480ml Bluetooth Smart Essential Oil Diffuser utilizes advanced cold air diffusion technology to effectively scent large areas without the need for water or heat. Its compact design allows for versatile placement, and smart controls offer customizable fragrance experiences.

Pagrindinės funkcijos:

• Platus aprėptis: Scents areas up to 2500 sq.ft.
• Cold Air Diffusion: Releases nano particles for efficient and pure scent distribution.
• Bevandenis veikimas: No water or alcohol dilution required, preserving essential oil purity.
• Lanksčios maitinimo parinktys: Can be powered by batteries (not included) or an adapter (included).
• Išmanusis Bluetooth valdymas: Manage power, scent levels (10 concentration levels), and timer functions via a dedicated app.
• Tylus veikimas: Designed for minimal noise, suitable for various environments.
• Universalus išdėstymas: Can be wall-mounted or used free-standing.

Gaminio matmenys:

Image: VEVOR Scent Air Machine with dimensions labeled. The unit measures 8.8 inches (224 mm) in length, 3 inches (77 mm) in width, and 9.3 inches (236 mm) in height.

Image: The VEVOR Scent Air Machine displayed in two usage scenarios: wall-mounted above a sofa and freestanding on a tabletop.

4. Sąrankos instrukcijos

Follow these steps to set up your VEVOR Scent Air Machine:

1. Išpakuoti: Atsargiai išimkite visus komponentus iš pakuotės.
2. Unlock Unit: Use one of the provided keys to unlock the side panel of the diffuser.
3. Išimkite butelį: Take out the empty essential oil bottle from inside the unit.
4. Užpildykite aliejumi: Fill the bottle with your desired fragrance oil. Ensure not to overfill.
5. Įdėkite butelį: Place the filled essential oil bottle back into its compartment, ensuring it is securely connected to the atomization core.
6. Power the Unit:
   • Baterijos galia: Insert four D-cell batteries (not included) into the battery compartment.
   • Adapterio galia: Connect the power adapter to the unit's power port and plug it into a suitable electrical outlet.
7. Restore Factory Settings (Optional): If needed, use a thin tool to long-press the 'SET' button inside the unit for 5 seconds to restore factory settings.
8. Uždaryti ir užrakinti: Close the side panel and lock it with the key to secure the internal components.

Demonstracinio vaizdo įrašo sąranka:

Video: This instructional video demonstrates the unboxing, filling of the essential oil bottle, battery installation, power connection, and factory reset process for the VEVOR Scent Air Machine.

5. Operating Instructions (Bluetooth App Control)

Control your VEVOR Scent Air Machine conveniently via the Bluetooth app:

1. Atsisiųsti programą: Ieškokite "Scent Marketing" in your device's app store (Google Play for Android, App Store for iOS) and download the application.
2. Select Bluetooth Version: Open the app and select the Bluetooth version for connection.
3. Connect to Diffuser: Find and select "Aroma Diffuser" from the list of available devices. The default password is "8888". Once connected, the Bluetooth indicator light on the diffuser will illuminate.
4. Patikrinkite alyvos lygį: Within the app, you can monitor the remaining essential oil level and calibrate it if necessary.
5. Valdymo funkcijos: Programėlė leidžia jums:
   • Įjunkite / išjunkite įrenginį.
   • Sureguliuokite ventiliatoriaus greitį.
   • Set working periods (start time, stop time, and specific days of the week).
   • Choose from 10 diffusion concentration levels (Grade 1-10) to customize fragrance intensity.
6. Išsaugoti nustatymus: After making any adjustments, ensure you click "Save" in the app to apply your new settings. The unit will operate according to preset schedules even when offline.

App Control Demonstration Video:

Video: This instructional video guides users through downloading the 'Scent Marketing' app, connecting to the VEVOR Aroma Diffuser via Bluetooth, and setting up working periods and scent intensity levels.

Image: A user interacting with the Bluetooth app on a smartphone, displaying options for manual adjustment, power control, 10 atomization levels, and timer functions for the VEVOR Scent Air Machine.

6. Priežiūra

Reguliarus valymas užtikrina optimalų difuzoriaus veikimą ir ilgaamžiškumą:

• Alyvos papildymas: When the essential oil level is low, unlock the unit, remove the bottle, and refill with new fragrance oil.
• Valymas: Periodically wipe the exterior of the unit with a soft, dry cloth. Do not use harsh chemicals or abrasive cleaners.
• Atomization Core: If you notice reduced scent output, the atomization core may need cleaning or replacement. Refer to the accessory kit for replacement parts if needed.
• Saugykla: If storing the unit for an extended period, ensure the essential oil bottle is empty and clean, and remove any batteries.

Image: The VEVOR Scent Air Machine with text emphasizing 'No Need for Water & Alcohol' for fragrance, and indicating an essential oil consumption rate of 0.08~0.6 g/h.

7. Problemų sprendimas

If you encounter issues with your VEVOR Scent Air Machine, try the following:

• No Scent Output:
  • Check if the essential oil bottle is empty and refill if necessary.
  • Ensure the atomization core is clean and not clogged.
  • Verify the unit is powered on and the app settings are correctly configured for scent output.
• Įrenginys neįsijungia:
  • Jei naudojate baterijas, patikrinkite, ar jos tinkamai įdėtos ir ar jose pakankamai įkrovos.
  • If using the adapter, ensure it is securely plugged into both the unit and a working power outlet.
  • Confirm the internal power switch is set to the correct power source (Battery or Adapter).
• „Bluetooth“ ryšio problemos:
  • Įsitikinkite, kad jūsų išmaniajame telefone įjungtas „Bluetooth“.
  • Make sure the diffuser is within Bluetooth range.
  • Try restarting the app and the diffuser.
  • Long-press the 'SET' button for 5 seconds to restore factory settings on the diffuser, then attempt to reconnect.

8. Specifikacijos

Image: A detailed graphic displaying the technical specifications of the VEVOR Scent Air Machine, including its model number, capacity, coverage area, power consumption, noise level, housing material, product dimensions, and net weight.

9. Garantija ir palaikymas

VEVOR provides comprehensive support for its products. For warranty information and technical assistance, please visit the official VEVOR support websvetainę.

• Gamintojas: VEVOR
• Elektroninis garantijos sertifikatas: Apsilankykite www.vevor.com/support
• Grąžinimo politika: 30 dienų pinigų grąžinimo / pakeitimo politika.
