DEXTER PP120 Smart Digital Handle Lock User Manual

Įvadas

This manual provides detailed instructions for the installation, operation, and maintenance of your DEXTER PP120 Smart Digital Handle Lock. Please read this guide carefully before attempting to install or operate the lock to ensure proper functionality and safety. Keep this manual for future reference.

Produkto savybės

The DEXTER PP120 Smart Digital Handle Lock offers multiple convenient and secure access methods:

• Programos valdymas: Unlock and manage your lock remotely via a dedicated smartphone application.
• Pirštų atspaudų atpažinimas: Fast and secure access using registered fingerprints.
• Rakto prieiga: Traditional mechanical key override for emergency situations.
• Numeric Passcode: Keypad entry with a customizable numeric code.
• Unlock Card: Convenient access using RFID unlock cards.
• IP53 atsparumas vandeniui: Designed to withstand splashes and dust, suitable for various environments.
• „Wi-Fi“ ryšys: Seamless integration with your home network for remote management and monitoring.

This image illustrates the DEXTER PP120 Smart Digital Handle Lock, highlighting its key features: App control, fingerprint recognition, key access, numeric passcode, unlock card functionality, IP53 water resistance, and Wi-Fi connectivity. The image also includes a table detailing model variations (PP120 and PP120 WIFI) with their article numbers, type (Embutir - Mortise), finish (Negro - Black), and master quantity.

Pakuotės turinys

Prieš pradėdami diegimą, patikrinkite, ar pakuotėje yra visi šie komponentai:

• Front Handle Assembly (with keypad and fingerprint sensor)
• Rear Handle Assembly (with battery compartment)
• Užrakto korpusas
• Sprogstamoji plokštė ir spragtukų dėžutė
• Tvirtinimo varžtai ir priedai
• Physical Keys (Emergency Override)
• Unlock Cards
• Vartotojo vadovas

Sąranka ir diegimas

Proper installation is crucial for the lock's performance. If you are unsure about any step, consult a professional locksmith.

1. Durų paruošimas: Ensure your door meets the lock's specifications regarding thickness and backset. Use the provided template to drill necessary holes if your door is not pre-drilled for a smart lock.
2. Užrakto montavimas: Insert the mortise lock body into the edge of the door. Secure it with the provided screws.
3. Handle Assembly Installation: Connect the cable from the front handle assembly to the rear handle assembly. Carefully align and insert the spindle and mounting posts through the mortise lock. Secure both handle assemblies to the door using the provided screws.
4. Akumuliatoriaus montavimas: Open the battery cover on the rear handle assembly. Insert four (4) AA alkaline batteries, ensuring correct polarity. Close the battery cover.
5. Programos atsisiuntimas ir susiejimas:
   • Download the DEXTER smart lock application from your device's app store.
   • Susikurkite paskyrą ir prisijunkite.
   • Follow the in-app instructions to add your new lock. This typically involves activating Bluetooth on your phone and bringing it close to the lock.
   • Once paired via Bluetooth, the app will guide you through connecting the lock to your home Wi-Fi network for remote access and advanced features.
6. Pradiniai nustatymai: Set up an administrator passcode and fingerprint through the app immediately after pairing.

Naudojimo instrukcijos

Durų atrakinimas

• Programėlės naudojimas: Open the DEXTER app, select your lock, and tap the unlock icon.
• Naudojant piršto atspaudą: Place a registered finger flat on the fingerprint sensor located on the handle. The lock will unlock if the fingerprint is recognized.
• Using Numeric Passcode: Touch the keypad to activate it. Enter your registered 6-10 digit passcode, followed by the '#' key.
• Using Unlock Card: Present a registered unlock card to the card reader area on the front handle. The lock will unlock upon successful recognition.
• Using Physical Key: In case of battery depletion or electronic malfunction, insert the physical key into the emergency keyhole (usually hidden) and turn to unlock.

Durų užrakinimas

• Automatinis užraktas: The lock is designed to automatically re-lock after a preset time (configurable in the app) once the door is closed.
• Rankinis užrakinimas (iš vidaus): Lift the handle upwards from the inside to engage the deadbolt.
• Manual Locking (via App): Use the DEXTER app to remotely lock the door.

User Management (via DEXTER App)

The DEXTER app allows you to manage access for various users:

• Pridedami vartotojai: Grant access to family members or guests by adding their fingerprints, creating unique passcodes, or assigning unlock cards.
• Modifying Access: Change existing passcodes, update fingerprints, or set time-limited access for specific users.
• Naudotojų ištrynimas: Revoke access by deleting user profiles, fingerprints, passcodes, or unlock cards.
• Prieigos žurnalai: View a history of who entered and when (requires Wi-Fi connection).

Priežiūra

To ensure the longevity and optimal performance of your DEXTER PP120 lock, follow these maintenance guidelines:

• Baterijos keitimas: Replace all four AA batteries when the low battery warning is indicated by the lock or in the app. Always use new, high-quality alkaline batteries. Do not mix old and new batteries or different battery types.
• Valymas: Spynos paviršių nuvalykite minkšta, sausa šluoste. Venkite naudoti abrazyvinius valiklius, tirpiklius ar stiprias chemines medžiagas, nes jos gali pažeisti apdailą ir elektroninius komponentus.
• Firmware atnaujinimai: Regularly check the DEXTER app for available firmware updates. Installing updates ensures your lock has the latest features, security enhancements, and bug fixes.
• Mechaninis patikrinimas: Periodically check that all screws are tight and the handle operates smoothly. Do not force the handle if it feels stiff.

Trikčių šalinimas

If you encounter issues with your DEXTER PP120 lock, refer to the following common problems and solutions:

• Užraktas nereaguoja:
  • Patikrinkite akumuliatoriaus lygį ir, jei reikia, pakeiskite.
  • Įsitikinkite, kad spyna tinkamai sumontuota ir visi laidai prijungti.
  • If using the app, ensure Bluetooth is enabled and you are within range.
• Piršto atspaudas neatpažintas:
  • Įsitikinkite, kad pirštas yra švarus ir sausas.
  • Pabandykite pirštą uždėti ant jutiklio skirtingose ​​vietose.
  • Jei problemos išlieka, ištrinkite ir iš naujo užregistruokite savo piršto atspaudą programėlėje.
• Numeric passcode not working:
  • Ensure you are entering the correct passcode followed by the '#' key.
  • Check if the passcode has expired or been disabled in the app.
• „Wi-Fi“ ryšio problemos:
  • Įsitikinkite, kad jūsų namų „Wi-Fi“ tinklas yra aktyvus ir stabilus.
  • Įsitikinkite, kad užraktas yra jūsų „Wi-Fi“ maršrutizatoriaus veikimo diapazone.
  • Try reconnecting the lock to Wi-Fi through the DEXTER app settings.
• Lock is jammed or stiff:
  • Do not force the handle.
  • Check for any obstructions in the door frame or mortise.
  • Ensure the lock is correctly aligned and installed.

Specifikacijos

Garantija ir palaikymas

For detailed warranty information, product registration, and technical support, please visit the official DEXTER website or contact DEXTER customer service directly. Keep your purchase receipt as proof of purchase for warranty claims.
