Įvadas
Thank you for choosing the Qaba Mercedes-Benz AMG CLA 45 12V Kids Electric Ride-On Car. This manual provides essential information for the safe assembly, operation, and maintenance of your new ride-on toy. Please read it thoroughly before use and retain it for future reference.
Image: A child in sunglasses sitting in the black Qaba Mercedes-Benz AMG CLA 45 electric ride-on car, showcasing jo dizainas.
Saugos informacija
ĮSPĖJIMAS: To avoid serious injury, adult supervision is required. Never use in roadways, near motor vehicles, on or near steep inclines or steps, swimming pools or other bodies of water. Always wear shoes. Never allow more than one rider. This product is not intended for children under 36 months due to small parts. Maximum weight capacity is 66 lbs (30 kg).
- Always ensure the child is securely seated and the safety belt is fastened.
- Operate the vehicle on flat, dry surfaces only. Avoid sand, loose dirt, or gravel.
- Laikykite rankas, plaukus ir drabužius atokiau nuo judančių dalių.
- Do not modify the electrical system.
- Įkraukite akumuliatorių tik su pateiktu įkrovikliu.
Pakuotės turinys
Atidžiai patikrinkite pakuotę, kad įsitikintumėte, jog yra visi reikalingi daiktai:
- Mercedes-Benz AMG CLA 45 Ride-On Car Body
- Vairas
- Ratai (4)
- Sėdynės
- Nuotolinio valdymo pultas
- Įkroviklis
- Instrukcijų vadovas
- 12 V įkraunama baterija (iš anksto įdiegta arba atskirai)
Sąranka ir surinkimas
Follow these steps to assemble your ride-on car. Refer to the diagrams for visual guidance.
- Rato montavimas: Attach each wheel to its axle, ensuring all washers and pins are correctly secured.
- Vairo tvirtinimas: Connect the steering wheel's electrical connector to the car's column, then firmly push the steering wheel onto the steering column until it clicks into place.
- Sėdynės montavimas: Place the seat onto the designated area and secure it with the provided screws or clips. Ensure the safety belt is accessible.
- Baterijos prijungimas: If the battery is not pre-connected, locate the battery compartment (usually under the seat) and connect the red terminal to the red wire and the black terminal to the black wire.
- Pirmasis įkrovimas: Before initial use, fully charge the battery for 8-12 hours. Do not overcharge.
Image: Detailed dimensions of the ride-on car, including length, width, height, and seat measurements.
Vaizdas: Stambus planas view of the steering wheel, showing the integrated music and horn controls.
Naudojimo instrukcijos
Rankinis valdymas
- Maitinimas: Paspauskite prietaisų skydelyje esantį maitinimo mygtuką.
- Pradėti/sustabdyti: Press the foot pedal to move forward or backward. Release the pedal to stop.
- Vairavimas: Norėdami pakeisti kryptį, pasukite vairą į kairę arba į dešinę.
- Greičio pasirinkimas: Use the speed switch on the dashboard to select between low and high speeds (1.9-3.1 mph).
- Interaktyvios funkcijos: Press the buttons on the steering wheel for horn sounds and pre-loaded music.
Nuotolinio valdymo pulto veikimas
The remote control allows parents to safely guide the vehicle. Ensure the remote control is paired with the car before use.
Image: A person holding the remote control, demonstrating its use for controlling the ride-on car from a distance.
- Poravimas: Follow the instructions in the remote control manual for initial pairing.
- Valdikliai: Use the directional buttons to move the car forward, backward, left, and right.
- Avarinis sustojimas: The remote control typically has an emergency stop button to halt the car immediately.
- Remote Priority: The remote control overrides manual operation for safety.
Papildomos funkcijos
- LED lemputės: The car features working LED headlights for enhanced realism.
- Spyruoklinė pakaba: Rear wheel suspension provides a smoother ride on various surfaces.
- Pagalbiniai ratai: When the power is off, the car can be easily moved using the auxiliary wheels located at the rear.
Image: An infographic highlighting the smooth driving experience provided by the rear wheel shock-absorbed system, suitable for various terrains.
Image: An infographic demonstrating how the auxiliary wheels allow for easy movement of the car when not in use.
Produkto vaizdo įrašas
Video: This video demonstrates the Qaba Mercedes-Benz AMG CLA 45 electric ride-on car in action, showcasing its features, movement, and interactive elements.
Akumuliatoriaus įkrovimas
- Įkrovimo prievadas: Locate the charging port on the vehicle (refer to the manual diagram if unsure).
- Prijunkite įkroviklį: Plug the charger into a standard wall outlet, then connect the charger's plug to the vehicle's charging port.
- Įkrovimo laikas: For optimal battery life, charge for 8-12 hours for the first charge. Subsequent charges should be 8-12 hours, or until the indicator light on the charger turns green. Do not charge for more than 18 hours.
- Baterijos tipas: This vehicle uses a 12V rechargeable battery.
- Sauga: Always charge in a dry, well-ventilated area. Do not allow children to charge the battery.
Priežiūra
- Valymas: Nuvalykite transporto priemonę minkšta, damp audinys. Nenaudokite abrazyvinių valiklių ar tirpiklių.
- Saugykla: Store the vehicle in a dry, cool place away from direct sunlight. If storing for extended periods, disconnect the battery and charge it monthly to prolong its lifespan.
- Akumuliatoriaus priežiūra: Venkite visiškai iškrauti bateriją. Įkraukite ją po kiekvieno naudojimo.
- Patikra: Reguliariai tikrinkite, ar nėra atsilaisvinusių varžtų, pažeistų laidų ar susidėvėjusių dalių. Nedelsdami pakeiskite visas pažeistas dalis.
Trikčių šalinimas
| Problema | Galima priežastis | Sprendimas |
|---|---|---|
| Automobilis nejuda | Battery is low or disconnected; Loose wire connection; Overload protection activated. | Charge battery; Check battery connections; Reduce load, wait a few minutes for reset. |
| Trumpas baterijos veikimo laikas | Battery not fully charged; Old battery; Frequent use on rough surfaces. | Ensure full charge (8-12 hours); Consider battery replacement; Use on smoother surfaces. |
| Nuotolinio valdymo pultas neveikia | Remote batteries low; Remote not paired; Interference. | Replace remote batteries; Re-pair remote control; Move away from other electronic devices. |
| Automobilis juda lėtai | Low battery; Overloaded; Motor issue. | Charge battery; Ensure rider weight is within limits; Contact customer support if motor issue suspected. |
Specifikacijos
- Modelio numeris: 370-353V80BK
- Gaminio matmenys: 43.3 x 24 x 17.7 colio (110 x 61 x 45 cm)
- Prekės svoris: 31.7 svaro (14.4 kg)
- Rekomenduojamas amžius: 36 mėnesių – 6 metų
- Baterija: 1 x 12 V (įtraukta)
- Greičio diapazonas: 1.9–3.1 mylių per valandą (3–5 km/h)
- Didžiausia svorio talpa: 66 svarai (30 kg)
- Gamintojas: Aosom LLC
Image: An infographic detailing key specifications such as dual motors, recommended age, weight capacity, and speed range.
Garantija ir palaikymas
For warranty information or technical support, please refer to the contact details provided with your purchase documentation or visit the official Qaba websvetainėje. Išsaugokite pirkimo įrodymą, jei prireiktų pateikti garantinį ieškinį.
