Veqotya AIR01 Portable Tire Inflator User Manual

Įvadas

Thank you for choosing the Veqotya AIR01 Portable Tire Inflator. This device is designed to provide convenient and efficient inflation for various items, including car tires, motorcycle tires, bicycle tires, and sports balls. It features a built-in pressure gauge, LED light, and a power bank function for emergencies. Please read this manual thoroughly before use to ensure proper operation and safety.

Pakuotės turinys

• Tire Inflator (1)
• Oro žarna (1)
• Atmospheric Nozzle (1)
• Stingy Mouthpiece (1)
• French Adapter (1)
• Ball Needle (1)
• USB įkrovimo laidas (1)
• Laikymo krepšys (1)
• Vartotojo vadovas (1)

Produkto savybės

• Didelės talpos baterija: Built-in 20000mAh rechargeable battery provides extended cordless operation.
• Greita infliacija: Delivers up to 150 PSI with an airflow rate of 36 L/Min, capable of inflating a standard car tire from 25-36 PSI in approximately one minute.
• Accurate & Automatic: Features a dual-digital LCD screen for real-time and preset tire pressure monitoring. Automatically stops inflation when the preset pressure is reached.
• Patogūs vartotojui režimai: Includes 4 preset inflation modes (bicycle, motorcycle, car, ball) and a customizable mode (3-150 PSI). Supports 4 pressure measurement units (PSI, KPA, BAR, kg/cm²).
• Avarinės funkcijos: Equipped with an LED emergency light and can function as a power bank via USB-C input and USB-A output ports.

Saugos informacija

• Nepalikite pripūtimo įrenginio be priežiūros veikiant.
• Laikyti vaikams nepasiekiamoje vietoje.
• Ensure the correct pressure is set for the item being inflated to prevent over-inflation.
• Avoid operating the device in wet conditions or near flammable materials.
• Do not use for large volume items like air mattresses or heavy-duty truck tires.
• The device may become warm during prolonged use. Allow it to cool down if necessary.

Sąranka

1. Įkraukite įrenginį: Before first use, fully charge the tire inflator using the provided USB charging cable. Connect the USB-C end to the inflator and the USB-A end to a compatible power adapter (not included). The battery indicator on the display will show charging status.
2. Pritvirtinkite oro žarną: Screw the air hose securely into the inflation port on the top of the device.
3. Pasirinkite tinkamą purkštuką: Choose the correct nozzle for the item you intend to inflate (e.g., atmospheric nozzle for car tires, ball needle for sports balls, French adapter for specific bike valves). Attach it to the other end of the air hose.

Naudojimo instrukcijos

1. Maitinimas: Press and hold the power button (usually marked with a 'U' or power symbol) for 3-5 seconds to turn on the inflator. The LCD screen will illuminate.
2. Prisijungti prie elemento: Connect the attached nozzle to the valve stem of the item you wish to inflate. The display will show the current pressure of the item.
3. Pasirinkite režimą: Press the 'M' (Mode) button to cycle through the preset modes (car, motorcycle, bicycle, ball) or the custom mode.
4. Nustatykite tikslinį slėgį: Use the '+' and '-' buttons to adjust the target pressure. The preset value will flash as you adjust it.
5. Pradėti infliaciją: Press the power button again to start the inflation. The device will automatically stop once the target pressure is reached.
6. Atsijungti: Carefully disconnect the nozzle from the valve stem. A small amount of air may escape, which is normal.

Režimai ir slėgio nustatymai

The Veqotya AIR01 offers versatile inflation options:

• Iš anksto nustatyti režimai: Easily switch between modes for Bicycle, Motorcycle, Car, and Ball. Each mode has a default pressure setting, which can be adjusted.
• Pasirinktinis režimas: For items not covered by presets, use the custom mode to set any pressure between 3-150 PSI.
• Slėgio vienetai: Toggle between PSI, KPA, BAR, and kg/cm² using the unit selection button.

Įkrovimo ir maitinimo banko funkcija

The device features a 20000mAh battery and can serve as a power bank:

• Charging the Inflator: Use the USB-C input port to charge the inflator.
• Išorinių įrenginių įkrovimas: Use the USB-A output port to charge mobile phones or other USB-powered devices in emergency situations.

Priežiūra

• Valymas: Nuvalykite įrenginį minkštu, sausu skudurėliu. Nenaudokite stiprių cheminių medžiagų ir nemerkite jo į vandenį.
• Saugykla: Pripūtimo įrenginį ir jo priedus laikykite pridėtame maišelyje vėsioje, sausoje vietoje, toliau nuo tiesioginių saulės spindulių ir ekstremalių temperatūrų.
• Akumuliatoriaus priežiūra: To prolong battery life, charge the device at least once every three months if not in regular use.

Trikčių šalinimas

Specifikacijos

• Prekinis ženklas: Veqotya
• Modelio pavadinimas: AIR01
• ttage: 12 voltų
• Maitinimo šaltinis: Maitinamas baterijomis
• Maksimalus slėgis: 150 PSI
• Oro srauto greitis: 36 l / min
• Baterijos talpa: 20000 mAh
• Triukšmo lygis: 68 decibelų
• Ypatingos savybės: Automatic Shut-Off, Digital Screen, Emergency Power Bank, LED Light, User-Friendly Preset Inflation Modes
• Spalva: Matinė juoda

Garantija ir palaikymas

This product comes with a standard manufacturer's warranty. For detailed warranty information, product support, or service inquiries, please refer to the contact information provided on the product packaging or visit the official Veqotya websvetainėje. Prašome išsaugoti pirkimo įrodymą garantiniams reikalavimams.
