GMAIPOP F19 4K Dash Cam Instruction Manual

1. Produktas baigtasview

The GMAIPOP F19 is a compact and powerful 4K Ultra HD dash camera designed to capture every detail of your journey. Featuring a 170-degree wide-angle lens, 5GHz Wi-Fi connectivity for seamless app control, and advanced night vision capabilities, it provides reliable high-definition evidence day or night. The dash cam includes a pre-installed 64GB high-endurance Micro SD card and supports up to 256GB for extended recording.

Figure 1: GMAIPOP F19 Dash Cam showing its compact size (2.4 inches high, 4.3 inches wide, 2.0 oz weight) and key features: 4K Front recording, 24H Parking Monitor, Free 64GB Card, 170° Wide Angle, and 5GHz WiFi.

Pagrindinės funkcijos:

• True 4K @30fps Front Recording: Captures crystal-clear video with a 170-degree wide-angle lens.
• 5GHz Wi-Fi & App Control: Fast video transfer and easy management via the Framefox app (iOS/Android).
• Discreet Mini Design: Žemas profasfile design for easy, unobtrusive installation.
• G jutiklis ir ciklinis įrašymas: Automatically detects collisions, locks footage, and overwrites old files for continuous recording.
• 24 valandų stovėjimo režimas: Monitors your vehicle when parked (requires optional hardwire kit) with time-lapse and impact detection.
• Super naktinis matymas: 4K Ultra-HD with advanced sensor and HDR for clear footage prasto apšvietimo sąlygomis.
• 64GB Micro SD Card Included: Ready to record out of the box, expandable up to 256GB.

2. Pakuotės turinys

Įsitikinkite, kad pakuotėje yra visi daiktai:

• GMAIPOP F19 4K Front Dash Cam
• Car Charger (DC adapter with power cord)
• Vartotojo vadovas
• 64GB Micro SD Card (pre-inserted in dash cam body)
• Automobilio laidų pjovimo įrankis
• 1 pc Electrostatic Film
• 5 vnt. kabelių spaustukai
• Lipnus kalnas

3. Sąrankos instrukcijos

3.1 Preparing the Windshield

1. Clean the area on your windshield where the dash cam will be mounted. Ensure it is dust-free and dry.
2. Apply the provided electrostatic film to the cleaned area. This helps protect your windshield and makes removal easier.

3.2 Vaizdo registratoriaus montavimas

1. Peel off the protective film from the adhesive mount on the dash cam.
2. Firmly press the dash cam onto the electrostatic film on your windshield, ensuring the lens has a clear view of the road. Hold for a few seconds to secure.

3.3 Maitinimo prijungimas

1. Connect the power cable to the dash cam's power port.
2. Plug the car charger (DC adapter) into your vehicle's cigarette lighter socket.
3. Use the provided car wiring trim tool and cable clips to neatly route the power cable along the edge of your windshield and dashboard, keeping it out of the way and ensuring a clean installation.

3.4 Initial Setup & SD Card Formatting

1. Upon first use, or if you replace the SD card, it is recommended to format the card using the dash cam. Press the power button to access the menu and navigate to the format option.
2. The dash cam must be connected to a power source to operate.

3.5 App Download & Connection

The F19 dash cam must be set up via the Framefox app.

1. Atsisiųskite Framefox app from your device's app store (iOS/Android).
2. On the dash cam, short press the power button to turn on Wi-Fi. The screen will display the Wi-Fi name (F19-*******) and default password (12345678).
3. On your smartphone or tablet, go to Wi-Fi settings and connect to the dash cam's Wi-Fi network using the provided password.
4. Open the Framefox app. Authorize the app to access your album, location, WLAN, and cellular data for proper functionality.
5. In the app, tap "Add Camera" and wait for the connection to establish. Once connected, you will see a live view iš vaizdo registratoriaus.

4. Naudojimo instrukcijos

4.1 Pagrindinis įrašymas

• Once powered on, the dash cam will automatically begin loop recording. Video segments are typically 1, 3, or 5 minutes long.
• Kai atminties kortelė pilna, rodoma seniausia atrakinta filebus automatiškai perrašyti naujais įrašais.

4.2 G jutiklis (avarinis įrašymas)

The built-in G-sensor automatically detects sudden shakes or collisions. When triggered, the current video segment is locked to prevent it from being overwritten by loop recording. This ensures critical footage is preserved as evidence.

Figure 2: Illustration of the G-Sensor detecting a collision and locking footage, alongside the continuous loop recording feature.

4.3 24 valandų parkavimo režimas

To enable 24-hour parking monitoring, a hardwire kit (sold separately) is required. Once installed, the dash cam can:

• „Time-Lapse“ įrašymas: Capture snapshots at set intervals (e.g., 1 frame every 1/5/10 seconds) after the ignition is off.
• Auto-Wake on Impact: Smart sensors activate full recording if someone bumps your car or suspicious activity is detected nearby.

Figure 3: Visual representation of the 24-Hour Parking Monitor, highlighting Collision Detection Mode and Time Lapse Mode, with a note that a hardwire kit is sold separately.

4.4 Super naktinis matymas

The F19 dash cam utilizes 4K Ultra-HD resolution combined with an advanced sensor and HDR (High Dynamic Range) function. This technology balances bright lights and dark areas, eliminating glare from headlights and street lamps, to capture sharp and clear footage net esant prastam apšvietimui ar nakties sąlygomis.

Figure 4: Depiction of the Super Night Vision capability, showing clear footage capture in a low-light environment with F/1.5 aperture, 6 Glass Lens, and WDR technology.

4.5 App Control (Framefox)

The Framefox app allows you to:

• Tiesiogiai View: Stebėkite, ką jūsų vaizdo registratorius įrašo realiuoju laiku.
• Review Footage: Browse through recorded videos and snapshots.
• Download & Share: Easily download videos and photos to your phone and share them without cables or monthly fees.
• Kameros nustatymai: Adjust various dash cam settings directly from the app.

Figure 5: Screenshot of the Framefox app interface on a smartphone, demonstrating live view, playback, download, and sharing options, powered by built-in 5GHz WiFi for faster transfers.

5. Priežiūra

5.1 SD kortelės valdymas

• The included 64GB high-endurance Micro SD card is designed for continuous recording.
• For optimal performance, it is recommended to format the SD card periodically (e.g., once a month) to prevent data corruption and ensure smooth operation.
• The dash cam supports up to 256GB Micro SD cards for extended recording capacity.

5.2 Valymas

• Reguliariai valykite vaizdo registratoriaus objektyvą minkštu, nepūkuotu skudurėliu, kad užtikrintumėte aiškią vaizdo kokybę.
• Use the provided wet and dry wipes to clean the windshield area around the dash cam mount as needed.

6. Problemų sprendimas

If you encounter any issues with your GMAIPOP F19 Dash Cam, please refer to the following common solutions:

• Vaizdo registratorius neįsijungia: Ensure the dash cam is properly connected to a power source. It does not have an internal battery for operation without external power.
• „Wi-Fi“ ryšio problemos: Verify that the dash cam's Wi-Fi is enabled. Ensure your phone's Wi-Fi is connected to the dash cam's network (F19-*******) and that the Framefox app has the necessary permissions (album, location, WLAN, cellular data).
• Įrašymo problemos: Format the Micro SD card using the dash cam's menu. Ensure the card is inserted correctly and is not full (loop recording should prevent this, but manual intervention might be needed if locked files accumulate).
• Prasta vaizdo kokybė: Clean the dash cam lens and ensure the windshield area is clear. Check app settings to confirm 4K recording is selected.
• Parkavimo režimas neveikia: Confirm that a hardwire kit is correctly installed and connected.

For more detailed troubleshooting steps, please consult the full user manual included in your package or contact GMAIPOP customer support.

7. Specifikacijos

8. Garantija ir palaikymas

For warranty information, product registration, or technical support, please refer to the contact details provided in the included user manual or visit the official GMAIPOP websvetainę. Išsaugokite pirkimo čekį garantiniams reikalavimams.
