1. Įvadas
The SereneLife Portable Evaporative Air Cooler (Model SLACSW538) is a versatile 3-in-1 unit designed to provide cooling, humidification, and fan functions. It features a high airflow of 2500 CFM, a large 8-gallon (30L) water tank, and convenient control options including LED touch, remote, and Wi-Fi app. This manual provides essential information for safe and efficient operation, maintenance, and troubleshooting of your unit.
2. Svarbios saugos instrukcijos
- Prieš naudodami prietaisą, atidžiai perskaitykite visas instrukcijas.
- Pastatykite įrenginį ant lygaus, stabilaus paviršiaus, kad jis neapvirstų ir neišsilietų vanduo.
- Neužblokuokite oro įleidimo ar išleidimo angų. Palaikykite pakankamą atstumą aplink įrenginį, kad būtų užtikrintas tinkamas oro srautas.
- Always unplug the unit from the power outlet before cleaning, performing maintenance, or when not in use.
- Prietaisą laikykite vaikams ir naminiams gyvūnėliams nepasiekiamoje vietoje.
- Do not operate the unit with a damaged power cord or plug. Contact customer support for assistance.
- Never immerse the electrical components of the unit in water or other liquids.
- Vandens bake naudokite tik švarų vandenį.
3. Pakuotės turinys
Patikrinkite, ar pakuotėje yra visi komponentai:
- SereneLife Portable Evaporative Air Cooler Unit
- Nuotolinio valdymo pultas su baterija
- (2) Ice Packs
- Vartotojo vadovas
4. Sąranka
4.1 Išpakavimas ir įdėjimas
Carefully remove the unit from its packaging. Place the air cooler on a firm, level surface in the desired location. Ensure there is sufficient space around the unit for optimal airflow.
4.2 Vandens bako užpildymas
The unit features an 8-gallon (30L) removable water tank for easy filling and cleaning. To fill the tank:
- Įsitikinkite, kad įrenginys yra atjungtas nuo maitinimo lizdo.
- Carefully detach the top section of the cooler from the water tank.
- Fill the water tank with clean, cool water up to the 'MAX' indicator line. Do not overfill.
- If desired, place the included ice packs into the water tank for enhanced cooling.
- Carefully reattach the top section, ensuring the water pump and power cord are not pinched and the latches are securely fastened.
Figure 1: Easy water tank filling and washable filter cleaning.
Figure 2: Advanced cooling technology with water circulation and ice packs.
4.3 Maitinimo prijungimas
Prijunkite maitinimo laidą į standartinį 120 V kintamosios srovės elektros lizdą. Įrenginys dabar paruoštas naudoti.
5. Naudojimo instrukcijos
5.1 Valdymo skydas baigtasview
The SereneLife SLACSW538 features an intuitive LED touch control panel on the top of the unit, along with a remote control and Wi-Fi app for convenient operation.
Figure 3: Simple touch control LED display and status lights.
5.2 Maitinimo įjungimas/išjungimas
Paspauskite ĮJUNGTA/IŠJUNGTA button on the control panel, remote, or via the app to turn the unit on or off.
5.3 Ventiliatoriaus greičio reguliavimas
Paspauskite Ventiliatoriaus greitis button to cycle through the available fan speeds (Low, Medium, High). The current speed will be indicated on the LED display.
5.4 Cooler/Humidifier Mode
Activate the cooling and humidifying function by pressing the Aušintuvas/drėkintuvas button. This mode utilizes water evaporation to cool and add moisture to the air. Ensure the water tank is filled for this function to operate effectively.
Figure 4: 3-in-1 comfort solution: air cooler, fan, and humidifier.
5.5 Supimo funkcija
Paspauskite Sūpynės button to activate the automatic oscillation of the vertical louvers, distributing air across a wider area. Press again to stop the oscillation.
5.6 Laikmačio funkcija
Set a desired operating time (up to 12 hours) by pressing the Laikmatis button. Each press will increase the timer setting. The unit will automatically turn off once the set time has elapsed.
5.7 „Wi-Fi“ valdymas
The unit can be controlled remotely via a dedicated mobile application. Follow the instructions provided in the app to connect your device to the air cooler's Wi-Fi network. This allows for convenient control from anywhere.
Figure 5: Smart control wherever you are via Wi-Fi app, remote, and touch panel.
Figure 6: Circulates cool air fast with 2500 CFM airflow and large 8-gallon tank.
6. Priežiūra
Regular maintenance ensures optimal performance and longevity of your evaporative air cooler.
6.1 Vandens bako valymas
To prevent mold and mildew growth, clean the water tank regularly, especially if the unit is used frequently. Unplug the unit, detach the top section, and empty any remaining water. Clean the tank with a mild detergent and water, then rinse thoroughly. Allow it to dry completely before reassembling.
6.2 Plaunamo filtro valymas
The unit is equipped with a washable filter and an auto-dry pad system. Periodically remove and clean the filter to maintain efficient airflow and cooling. Rinse the filter under running water to remove dust and debris. Ensure the filter is completely dry before placing it back into the unit.
6.3 Saugykla
If the unit will not be used for an extended period, drain and clean the water tank and filter. Store the unit in a cool, dry place, away from direct sunlight and extreme temperatures.
7. Problemų sprendimas
If you encounter issues with your SereneLife Evaporative Air Cooler, refer to the following common problems and solutions:
| Problema | Galima priežastis | Sprendimas |
|---|---|---|
| Įrenginys neįsijungia | No power supply; Unit not properly assembled | Check power cord connection; Ensure unit sections are securely latched. |
| Nėra vėsaus oro / Silpnas aušinimas | Low water level; Cooler/Humidifier mode off; Dirty filter; No ice packs | Fill water tank; Activate Cooler/Humidifier mode; Clean filter; Add ice packs to water tank. |
| Silpnas oro srautas | Low fan speed setting; Blocked air inlets/outlets; Dirty filter | Increase fan speed; Clear obstructions; Clean filter. |
| Neįprastas triukšmas | Obstruction in fan; Unit not on level surface | Patikrinkite, ar nėra kliūčių, ir jas pašalinkite; pastatykite įrenginį ant stabilaus, lygaus paviršiaus. |
| Vandens nutekėjimas | Water tank not properly seated; Drain plug loose | Ensure water tank is correctly positioned and latched; Check and secure drain plug. |
8. Specifikacijos
| Funkcija | Detalė |
|---|---|
| Prekės ženklas | SereneLife |
| Modelio pavadinimas | SLACSW538 |
| Montavimo tipas | Pastatomas |
| Spalva | Baltas |
| Oro srauto talpa | 2500 kubinių pėdų per minutę (CFM) |
| Valdymo tipas | Touch, Remote, Wi-Fi App |
| Rezervuaro talpa | 30 litro (8 galono) |
| Rekomenduojami naudojimo būdai | Gyvenamieji |
| Triukšmo lygis | ≤52 dB |
| Greičių skaičius | 3 |
| Gaminio matmenys | 19.54 "D x 14.75" P x 34.24" A |
| ttage | 120 voltų |
| Prekės svoris | 20.7 svaro |
| Medžiaga | Acrylonitrile Butadiene Styrene (ABS), HIPS, PC, Polypropylene (PP) |
| UPC | 842893175928 |
Figure 7: Product dimensions for the SereneLife Evaporative Air Cooler.
9. Garantija
This SereneLife product comes with a 1 metų garantija from the date of purchase. Please retain your proof of purchase for warranty claims. For detailed warranty terms and conditions, refer to the official SereneLife websvetainėje arba susisiekite su klientų aptarnavimo tarnyba.
10. Pagalba klientams
For any questions, technical assistance, or warranty inquiries, please contact SereneLife Customer Support:
- Apsilankykite oficialioje „SereneLife“ svetainėje websvetainė, kurioje rasite pagalbos išteklius ir kontaktinę informaciją.
- Žiūrėkite kontaktinę informaciją, pateiktą ant jūsų produkto pakuotės.
